Solution: Incorrect folder If a font file is located in the same folder as the DWG file that uses it, AutoCAD will find it. However, the standard location for SHX fonts is in the AutoCAD Fonts folder, located in C: Program Files Autodesk AutoCAD 20xx Fonts.

If putting the missing font into the Fonts folder does not stop the error message, check the following: • Open the Options dialog box by typing OP at the command line. • On the Files tab, expand the Support File Search Path entry. • Make note of the path pointing to the fonts. ​AutoCAD for Mac paths: • /Applications/Autodesk/AutoCAD 201x/AutoCAD 201x.app/Contents/Resources/Fonts/shx/ • /Applications/Autodesk/AutoCAD LT 201x/AutoCAD LT 201x.app/Contents/Resources/Fonts/shx/ Note: If the file has been received from a third party, ask to have it saved using.

The font will be packed together with the drawing file. Corrupt font file If the SHX file is in the AutoCAD Fonts folder and the program still does not show the font in the text editor, the file is corrupt or otherwise unreadable by AutoCAD.

Apr 22, 2014 - The answer, it turns out, was to use an SHX font: this allowed the transient text to be displayed properly from the start and with the colour the.

Obtain another copy of the SHX font file and use it to replace it. Damaged AutoCAD settings files It is possible that AutoCAD is loading corrupted data when it starts and needs to be reset to defaults in order for font files to be correctly recognized (see ). Replacing missing font If the original font is missing and cannot be obtained, it is possible to replace the missing SHX font with another one. • Open the affected drawing.

• When prompted, choose Specify a replacement for each SHX file.

Solution: AutoCAD supports SHX and TrueType fonts. Installing an SHX font: Copy.shx files into the Fonts folder within the AutoCAD program folder: C: Program Files Autodesk AutoCAD 20xx Fonts Note: PostScript fonts (.pfb) and shape files (.shp) can be converted to.shx by using the command in AutoCAD. Installing a TrueType font: AutoCAD reads TrueType (.ttf) fonts that are installed in the operating system.

TTF files do not go into AutoCAD's own Fonts folder. Copy.ttf files into: C: Windows Fonts As an alternative, you may right-click a.ttf file and choose Install. Note: Windows XP and Vista systems require going to the Control Panel and opening Fonts and then using 'Install new font' under the Font menu.
